SD-2xIn: 2x DI (Digital Input) with S0 pulses to the Portal

SD-2xIn is a device for connecting to the Portal door contacts, PIR motion detectors or smoke (gas) detectors with a dry contact output. 2x DI (Digital Input) on the SD-2xIn device allows connecting 2 external independent detectors. Each DI can also count S0 pulses, so even Water / Gas / Electricity meters with pulse outputs can be connected.

For device configuration (WiFi network setup) can be used a built-in web server, but generally no on-site device configuration requires. The device is connected to the Portal (SensDesk Technology). From the portal are data accessible on the Mobile Apps (SensDeskMobile or HWg Monitor). If the device is correctly configured in the SensDesk portal, it can send an e-mail alert whenever the specified range of values is exceeded. If you also use our SMS-GW3 together with the portal, the alerts can be also sent as text messages (SMS).

Features:
  • 2 independent DI (Digital Inputs) which count pulses (S0 counter) to the Portal.
  • Device is connected to the portal via LAN / WiFi
  • Portal is mandatory (any SensDesk Technology based portal)
  • Portal services: Graphs, PDF reports, Email & SMS Alerting, SNMP, XML Open API
  • Default portal: HWg-cloud.com (free service)
  • Power: Power adaptor (5V) or PoE
  • Metal housing, DIN and rack mount available
  • WiFi network setup: Embedded WEB server
Applications and usage:
  • Remote monitoring of simple detectors (door contact, smoke, power)
  • Connecting 3rd party devices to the Portal (via relay outputs)
  • Metering water consumption (meter with S0 pulse output)
  • Metering electricity (kWh) consumption from meter with pulse output

Horizontal menu

Digital Inputs for common 3rd party detectors

DI (Digital Input) for dry contact (relay output) is the most popular electrical interface for 2-state detection (doors opened/closed or water tank Full/empty).
Counting pulses on DI is a useful feature enabling applications for energy/water consumption. Simply connect the water meter with pulse output to the SD-2xIn device and the water meter is monitored in the (SensDesk Technology based) Portal.

You can connect:

  • Door contact
  • Smoke/gas detector (relay output)
  • Generic relay / Open Collector output
  • Water / Gas Meter with pulse output (S0)
  • Electricity Meter with pulse output (S0)



SD-2xIn



User benefits

  • Device installation on the site is fast & easy even for “Junior users”.
  • Portal will alert you by email (SMS, Voice Call) if DI is switched On/Off.
  • Portal will alert you if the device is disconnected for 1 hour.
  • Alarm state (0 / 1) can be defined for each DI
  • Free cloud available (HWg-cloud.com) with graphs and device management.
  • Mobile Apps can show you all detectors states in your portal account (HWg Monitor or SensDesk Mobile)
  • SMS, Voice call alerts, graphs & PDF reports can be used with paid portal services.



Portal is required

All SensDesk Technology logoIoT Monitoring Devices have to be connected to any SensDesk Technology-based portal (SaaS) in order to work properly.

The SensDesk Technology is a portal solution from the HW group to manage remote sensors and devices (only for HW group products). Portals offer a central overview of all the values and provide a variable combination of features like sending the alarms, reporting, history records, outputs into the Open API, etc.


There are several portals available. The manufacturer provides HWg-cloud.com and SensDesk.com, 3rd party companies provide more than 10 other portals. Users can migrate the device between any available SensDesk Technology portals.

 u

HWg-cloud.com: Limited & Free portalHWg-cloud.com portal features - Portal Providers icons

  • the default pre-configured portal option
  • provided by the device manufacturer
  • sends email alerts and offers basic remote device management
  • advanced features of SensDesk Technology are not available
  • You can migrate your devices from HWg-cloud.com to any other SensDesk Technology portal at any time






SensDesk.com: Paid portal service with advanced featuresSensDesk.com portal features icons

  • Several subscription plan options
  • SMS / Voice call alerts to any mobile phone
  • Graphs / MultiGraphs (data history)
  • PDF reports
  • Email alerts/alarm escalation
  • History log
  • Open API: All sensor values are available via XML / SNMP protocols





Local portals by Portal providersSensDesk Technology portal features - Portal Providers icons

  • portals based on SensDesk Technology ran by 3rd party providers
  • local languages and support
  • various mix of free/paid services
  • various commercial names





Why do you need a portal?

  • Using the portal makes the IoT monitoring devices easy to install even by junior local staff. To install the IoT devices you don´t need any experts on the site.
  • The portal can then send alerts, provides remote device management. Portal is one place with all your sensors & graphs overview, reporting, Open API, ...
  • Even the default free of charge version of the portal (Hwg-cloud.com) can alert you by email when device disconnected / sensor value alarm.
  • Price of the SensDesk.com portal service is around 15 % of the hardware cost per year.



All your sensors are in your pocket 24/7Mobile App HWg Monitor icon

You can have a display with all your sensor values in your pocket with you 24/7. Check HWg Monitor mobile app. The app can be running on your phone, on the Android TV, or on the Tablet installed on the wall.



AlertingAlert icon

SensDesk.com can immediately alert you by SMS or Voice call to your mobile phone in the case of an Alarm situation. If the time is critical, every second counts. The immediate reaction to an alarming situation can be also responded to by closing/opening a remote relay output, which can for example turn on a siren. Quick alerts lower the risk of costly damages in case of an Alarm. Alerts from the portal can escalate to higher intensity or to another person if the problem persists.



Sensor values in MultigraphsMultigraph icon

Multigraphs can display multiple sensor values from different kinds of sensors in one graph. That offers a situation overview of a remote site, significant fluctuance of sensor values is visible at first sight. It is popular for comparing time events. SensDesk.com system is also showing sensor value graphs that alert you when the device is not working or any sensor is out of defined limits.

For an example of working with charts in SensDesk, see the application note.


PDF reportsreport icon

You can easily create comprehensible reports with graphical representations of sensor values in one or in a number of locations. You can create reports in PDF (CSV) periodically. Reports can be printed & clicked to the invoice for your customer. Reports for pharmaceutical / other production (HACCP) are possible.




HistoryHistory icon

Thanks to the history log you can easily compare your historical data.





Open API Open API icon

You can connect the data from SensDesk.com to any other system. Portal user account (all connected sensors) is accessible by Open API (SNMP, XML).

  • A list of all the sensors / current values can be downloaded in XML format (HTTP get).
  • All the values can be read via SNMP v1 / v3 protocol.





The number of Dashboards, Multigraphs and Reports is limited by the subscription plan as well as the length of the history log, check the plans: www.sensdesk.com
